Cymhwyso Gwifren Tymheredd Uchel ASTVRP:
Defnyddir gwifren drydan ASTVRP yn bennaf ar gyfer offer offer trydan, rhyng-gysylltydd offer ac offeryn, Gwifrau mewnol offer electronig trydanol ac offer awtomeiddio, ac ati.
Mantais ASTVRP
Mae ganddo gymeriad da Gwrth-ymyrraeth, ymwrthedd olew, gwrth-cyrydiad, gwrth-heneiddio ac ati.
Strwythur Gwifren Tymheredd Uchel ASTVRP:
Copr noeth wedi'i orchuddio, neu Arweinydd copr tun gyda lapio sidan, inswleiddio PVC PVC / ROHS, Tarian plethedig gwifren gopr copr haen allanol
Lliw:lliw gwyn arian.
Foltedd:
300 / 500V ac is
Tymheredd gweithio:
-20 ℃ -75 ℃ Max.105 ℃
Data Technegol ar gyfer rhan o ASTVR Wire, Gwifren Tymheredd Uchel ASTVRP
Ardal | Strwythur (mm) | Max.OD (mm) | Gwrthiant arweinydd ar 20 ℃ | Gwrthiant inswleiddio yn 70 ℃ | Pwysau wedi'u cyfrifo Kg / km | ||
mm2 | Rhifau Stranding / dia. y wifren | ASTVR | ASTVRP | ≤Ω / km | ≥MΩ·m | ASTVR | ASTVRP |
0.06 | 7/0.1 | 1.5 | 1.9 | 384 | 17 | 2.1 | 6.0 |
0.1 | 12/0.1 | 1.6 | 2.0 | 214 | 17 | 2.8 | 7.2 |
0.12 | 7/0.15 | 1.8 | 2.2 | 163 | 16 | 3.1 | 7.5 |
0.14 | 7/0.16 | 1.9 | 2.3 | 143 | 16 | 3.4 | 7.9 |
0.2 | 7/0.2 | 2.0 | 2.4 | 95.0 | 14 | 4.4 | 9.3 |
0.3 | 16/0.15 | 2.1 | 2.5 | 71.2 | 14 | 5.4 | 10.7 |
0.35 | 20/0.15 | 2.1 | 2.5 | 57.0 | 12 | 6.2 | 11.6 |
0.4 | 23/0.15 | 2.3 | 2.7 | 49.6 | 12 | 7.2 | 13.0 |
0.5 | 16/0.2 | 2.5 | 2.9 | 40.1 | 12 | 9.3 | 15.8 |
0.75 | 24/0.2 | 2.7 | 3.1 | 26.7 | 10 | 12.7 | 20.0 |
1.0 | 32/0.2 | 2.9 | 3.4 | 20.0 | 10 | 17.0 | 25.4 |
1.5 | 30/0.25 | 3.2 | 3.9 | 13.7 | 9 | 23.1 | 37.3 |
2.0 | 49/0.23 | 3.5 | 4.1 | 10 | 9 | 27 | 41 |
2.5 | 49/0.25 | 3.8 | 4.4 | 8.21 | 8 | 34 | 50 |
